Ko-ken 3300XZ-17 3/8 Sq. Dr. Socket 17mm 6 point Length 35mm Z-series

Ko-ken 3300XZ-17 3/8 Sq. Dr. Socket 17mm 6 point Length 35mm Z-series

A socket is a tool used in conjunction with a ratchet, wrench, or other driver to tighten or loosen fasteners such as bolts or nuts. It typically has a cylindrical shape with a hexagonal opening on one end, designed to fit over a corresponding fastener. The opposite end attaches to a ratchet handle, breaker bar, or torque wrench.

Product Specifications

• Drive Shape: Square
• Input Drive Size: 3/8"
• Length: 35mm
• Opening: 6 Point
• Output Size: 17mm
• Type: Semi Deep 6 Point Socket
• Product Dimension (Refer Line Drawing Image):
• D1 Size: 22.5mm
• D2 Size: 20.5mm
• H1 Size: 16.5mm
• H2 Size: 23mm
• L Size: 35mm
