Ko-ken 4100M-16 27mm Hex Stud puller 16mm

Ko-ken 4100M-16 27mm Hex Stud Puller 16mm

Screw and Stud Pullers Hexagon body design can lessen the excessive load on cages and rollers inside the pullers. 4100M-16 is designed not to have 1/2" Sq. drive. Repair Kit: A stud bolt could not pass through 4100M-16 if it had the 1/2" Sq. drive, since 16mm stud bolt is bigger than 1/2" Sq. drive. (Also, 4100A-5/8 does not have 1/2" Sq. drive with the same reason.) As it mentions on our catalogue, please drive the outer hexagon part with 27mm socket or ring wrenches.

Product Specifications

• Drive Shape: Square
• Length: 75mm
• Opening: 27mm Hexagon
• Output Size: 16mm
• Type: Screw and Stud Puller
• Note: 4100M-16 and 4100A-5/8 do not have 1/2'' square drive. Drive the outer hexagon part with 27mm sockets or ring wrenches.
• Product Dimension (Refer Line Drawing Image):
• D Size: 34mm
• H Size: 27mm
• L Size: 75mm
