Ko-ken 6100M-18 3/4 Sq. Dr. Stud puller 18mm 36mm Hex Length 100mm

Ko-ken 6100M-18 3/4 Sq. Dr. Stud Puller 18mm 36mm Hex Length 100mm

A stud puller is a specialized tool used for removing or installing threaded studs from engine blocks, machinery, or other mechanical components. It works by gripping the stud securely, allowing for the application of torque to either extract the stud from its seated position or install it without damaging the threads. The tool typically has a cam or collet mechanism that tightens around the stud as torque is applied, ensuring a firm grip.

Product Specifications

• Drive Shape: Square
• Input Drive Size: 3/4"
• Length: 100mm
• Opening: 36mm
• Output Size: 18mm
• Type: Stud Puller
• Note: 6100M-22 to -30 do not have 3/4'' square drive. Drive the outer hexagon part with sockets or ring wrenches(size 22-24mm = 36H, 27-30mm = 46H).
• Product Dimension (Refer Line Drawing Image):
• D Size: 48mm
• H Size: 36mm
• L Size: 100mm
